A touch-screen 12-lead ECG machine compatible with stress-testing systems. Suitable for use with treadmills and bicycles. Data management software and a mobile cart are available.
Preview report for both real-time printing and file storage.
Edit the printing style, printing speed, sensitivity and filter setting to get better waveforms instead of spending time performing repeated examinations.
Freeze and review waveform backward and forward per second or page to grasp every arrhythmia, then print.
Patient data in internal storage including waveforms, measurement and diagnosis which could also be enlarged by flash drive or PC hard disk, support report search from internal memory.
Input Circuit: Defibrillation protection built-in
Lead Standard: 12 leads
Acquisition Mode: Simultaneous 12-lead acquisition (10-24 seconds adjustable)
A/D Converter: 24 bits
Input Voltage Range: Ãƒ,Ã‚Â±5mVpp
Time Constant: >3.2s
Frequency Response: 0.05Hz - 150Hz
Calibration Voltage: 1mVÃƒ,Ã‚Â±2%
Sensitivity: 2.5, 5, 10, 20, 10/5.AGC (mm/mV)
Input Impedance: 50M ÃƒÂŽÃ‚Â© (10Hz)
Input Circuit Current: <10nA
Noise Level: <12.5 ÃƒÂŽÃ‚Â¼ A Vp-p
Anti Baseline Drift: Automatic
Patient Leakage Current: <10 ÃƒÂŽÃ‚Â¼ A (220V-240V)
Patient Auxiliary Current: <0.1 ÃƒÂŽÃ‚Â¼ A (DC)
Filter: EMG filter 25 Hz/35Hz/45Hz/OFF, DFT filter 0 .05/0.15/0.25/ 0.5/0.32/0.67Hz, Lowpass filter 150Hz/100Hz/75Hz, AC filter 50Hz/60Hz
Recording Mode: Auto/Manual/Rhythm/R-R Analyze
Rhythm Lead: Single lead or three leads selectable
Power Supply: AC:100V-240V, 50/60Hz
Battery: Built-in rechargeable Li-ion battery
Voltage: 14.4V, for about 400 copies ECG printing
Recorder: Thermal paper
Record paper: Fled paper, rolled paper
Paper width: 216mm, 210mm
Record speed: 5mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s (Ãƒ,Ã‚Â±3%)
Dimension: 420mm x 330mm x 120mm
Display: 800 x 600 multicolor LCD
External Input/Output: Input > 100 K ÃƒÂŽÃ‚Â© : Sensitivity 10mm/V Ãƒ,Ã‚Â± 5%, Output < 100 ÃƒÂŽÃ‚Â© : Sensitivity 1V/mV Ãƒ,Ã‚Â± 5%
Communication Ports: Ethernet, RS232
